Description
- The entire machine surface uses a new powder coating and baking paint process, offering better aesthetics, rust resistance, and corrosion resistance.
- Uses 8-modulus reinforced gears and a ductile iron gearbox with a height between traditional medium and high gearboxes, making it more suitable for matching with high-horsepower 4WD tractors.
- Features a new arc-shaped cover for easier disassembly, assembly, and cleaning.
- Incorporating advantages of foreign products, the dragboard features a new streamlined design and thickened plates for better leveling effect and longer service life.
- The blade shaft is welded with large arc blade holders for higher strength. Matched with new material rotary blades, service life can be increased by 3 times compared to traditional 65Mn blades.
- Uses reinforced frame and hitch, comprehensively improving the overall machine strength.
Technical Specification
Standard Configuration of G7 Series Rotary Cultivator
| Output Shaft Speed (r/min) | 766;282 |
| Connection Method | Three-point hitch |
| Power Transmission Method | Central transmission |
| Blade Type | IT245 |
G7 Series Rotary Cultivator Options
| Coding Series | Gear Modulus | Gearbox Center Distance | Pinion Teeth | Bevel Gear Teeth | Input Speed | Design Output Speed | Matched Tractor Horsepower(HP) |
| Medium Box Series Rotary Tiller | 8 | 430 | 14 | 26 | 766 | 282 | 80-120 HP |
| 15 | 22 | 540 | 252 |
| Model | HP | Working Width(m) | Dimensions(mm) L×W×H | Max. Tillage Depth(cm) | Blade Qty | Weight(kg) |
| 1GKN-210 | 80-89 | 2.1 | 1065×2335×1185 | 8-16 | 56 | 525 |
| 1GKN-230 | 90-120 | 2.3 | 1065×2535×1185 | 8-16 | 68 | 550 |
Company Advantages
LEROX is dedicated to delivering full-scenario implement solutions for modern agriculture. Our extensive product matrix spans multiple operational dimensions, offering an all-inclusive range from agile, compact models to heavy-duty flagship designs. Seamlessly matching mainstream power platforms from 80 to 600 horsepower, LEROX provides tailor-made equipment combinations that ensure high-efficiency, continuous, and synergistic operations worldwide—regardless of soil types or farming environments.
From primary tillage and precision seeding to crop management and harvesting, every core chassis and critical component of LEROX machinery is forged and proven under the most extreme field conditions. Empowered by advanced intelligent control systems and robust overload protection technologies, our equipment delivers stable, uncompromising performance in any harsh environment. More than just a machinery manufacturer, LEROX is a guardian of modern agronomy—reducing full lifecycle operating costs and creating long-term, value-driven smart returns for agricultural producers worldwide.
