Description
- Designed for high-clearance, high-horsepower tractors, it features an enlarged gearbox with large-modulus, high-strength gears. It is 10 cm taller than the large-medium gearbox series models, making the tractor PTO output and cultivator power input horizontal, greatly extending the service life of the PTO drive shaft.
- A new integrated hitching frame makes the machine connection more secure, and new-style bearing housings improve sealing performance.
- This series can be equipped with specialized deep tillage blade shafts and extended rotary blades, achieving a tillage depth of 35-40 cm under suitable conditions, making it an ideal choice for your high tillage depth requirements.
- Our company, targeting diverse soil structures, different work habits, and market demands across the country, employs automotive manufacturing concepts to design and produce this series of framed, variable-speed, high-efficiency rotary cultivators compatible with 100-200 HP tractors. They feature high overall strength, good power matching, compact structure, low power consumption, flexible operation, and high work quality. Capable of working normally under harsh soil conditions, the gearbox uses a speed change mechanism, allowing you to select a more suitable working speed.
- Made with ductile iron casting for higher strength, making it more suitable for high-horsepower tractors. Designed in high, medium, and low three sizes for easy matching with tractors across multiple power ranges, ensuring the PTO drive shaft and tractor power take-off shaft work under better conditions. Equipped with 10-modulus thickened gears, ensuring the strength of core components and higher operational reliability.
Technical Specification
Standard Configuration of G5 Series Rotary Cultivator
| Output Shaft Speed (r/min) | 766;281 r/min |
| Cultivator Transmission Method | Central transmission |
| Cultivator Blade Roller Max. Rotation Radius | 245 mm |
| Blade Type | IT245 |
G5 Series Rotary Cultivator Options
| Coding Series | Gear Modulus | Gearbox Center Distance | Pinion Teeth | Bevel Gear Teeth | Input Speed | Design Output Speed | Matched Tractor Horsepower(HP) |
| High-Capacity Box Series Rotary Tiller | 10 | 610 | 13 | 27 | 766 | 300 | 140-160 Horsepower four-wheel drive |
| 15 | 23 | 540 | 286 |
| Model | HP | Working Width(m) | Overall Dimensions(mm) L×W×H | Max. Tillage Depth(cm) | Blade Qty | Weight(kg) |
| 1GKN-250 | 100-130 | 2.5 | 2743×1111×1273 | 12~18 | 68 | 680 |
| 1GKN-270 | 120-150 | 2.7 | 2932×1142×1334 | 12~18 | 72 | 707 |
| 1GKN-300 | 150-180 | 3 | 3232×1142×1334 | 12~18 | 88 | 771 |
| 1GKN-330 | 150-180 | 3.3 | 3532×1142×1334 | 12~18 | 92 | 791 |
