Description
- Designed for high-clearance, high-horsepower tractors, it features an enlarged gearbox with large-modulus, high-strength gears. It is 10 cm taller than the large-medium gearbox series models, making the tractor PTO output and cultivator power input horizontal, greatly extending the service life of the PTO drive shaft.
- A new integrated hitching frame makes the machine connection more secure, and new-style bearing housings improve sealing performance.
- Our company, targeting diverse soil structures, different work habits, and market demands across the country, employs automotive manufacturing concepts to design and produce this series of framed, variable-speed, high-efficiency rotary cultivators compatible with 120-200 HP tractors. They feature high overall strength, good power matching, compact structure, low power consumption, flexible operation, and high work quality. Capable of working normally under harsh soil conditions, the gearbox uses a speed change mechanism, allowing you to select a more suitable working speed.
- Made with ductile iron casting for higher strength, making it more suitable for high-horsepower tractors. Equipped with 10-modulus thickened gears, ensuring the strength of core components and higher operational reliability.
Technical Specification
Standard Configuration of G3 Series Rotary Cultivator
| Output Shaft Speed (r/min) | 766;282 r/min |
| Cultivator Transmission Method | Central transmission |
| PCultivator Blade Roller Max. Rotation Radius | 245 mm |
| Cultivator Blade Type | IT245 |
G3 Series Rotary Cultivator Options
| Coding Series | Gear Modulus | Gearbox Center Distance | Pinion Teeth | Bevel Gear Teeth | Input Speed | Design Output Speed | Matched Tractor Horespower(HP) |
| High-box series rotary tiller | 10 | 520 | 15 | 23 | 540 | 241 | 120-200 Horsepower four-wheel drive |
| 14 | 26 | 766 | 282 |
| Model | HP | Working Width(m) | Overall Dimensions(mm) L×W×H | Max. Tillage Depth(cm) | Blade Qty | Weight(kg) |
| 1GKN-230 | 120-140 | 2.3 | 1065×2535×1185 | 12～18 | 64 | 550 |
| 1GKN-250 | 150-160 | 2.5 | 1165×2740×1340 | 12～18 | 72 | 580 |
| 1GKN-270 | 180-200 | 2.7 | 3056×1142×1334 | 12～18 | 76 | 670 |
