HomeProductsTillage EquipmentRotary CultivatorG0 Low-Gearbox Series Rotary Cultivator
Rotary Cultivator

G0 Low-Gearbox Series Rotary Cultivator

This product incorporates lean production and streamlined design, featuring electrostatic plasma-sprayed components and synchronized assembly line manufacturing.

Model:
 1GKN-125/130/140/150
Working Width:
 1.25 m/1.3 m/1.4 m/1.5 m
Blade Type:
 IT245

Description

  1. This product incorporates lean production and streamlined design, featuring electrostatic plasma-sprayed components and synchronized assembly line manufacturing.
  2. The blade shaft is welded by robotic systems and equipped with dust covers, effectively protecting the bearings from harsh operating environments and extending service life.
  3. The low-gearbox series rotary tillers utilize a centrally mounted, compact ductile iron gearbox with module 6 gear transmission. Designed to complement tractors from 18 to 40 HP, with working widths ranging from 125cm to 150cm, the machine is lightweight yet durable, making it the preferred choice for tilling and harrowing operations in small plots.

Technical Specification

Standard Configuration of G0 Series Rotary Tiller

PTO Shaft Speed (r/min)766; 262
Linkage TypeThree-point linkage
Power Transmission TypeCentral drive
Blade TypeIT245

Optional Configurations for G0 Series Rotary Tiller

Standard rotary tillerCan be equipped with a cage rollerCan be equipped with a stubble mulching blade shaftWear-resistant rotary blades, tripling the tilling acreage compared to standard bladesCan be equipped with premium stubble mulching bladesForged blade brackets, increasing quality by 2–3 times compared to cast blade brackets
Coding SeriesGear ModulusGearbox Center DistancePinion TeethBevel Gear TeethInput Speed Design Output SpeedMatched TractorHorsepower (HP)
Low-box series rotary tiller6380112576626218-40
1423540256
ModelHPWorking Width(m)Overall Dimensions(mm) L×W×HMax. Tillage Depth(cm)Blade QtyWeight(kg)
1GKN-12518-251.25980×1440×11008-1630175
1GKN-13020-251.30980×1490×10808-1630190
1GKN-14025-301.40980×1585×10808-1634220
1GKN-15030-401.50980×1685×10308-1638238
