Description
The 9YG-2.28 round baler incorporates five core systems: mechanical transmission, pickup and baling, hydraulic control, electrical control, and net wrapping mechanism. It sequentially performs operations including pickup and feeding, rolling and forming, net wrapping, and bale unloading, making it suitable for the large-scale collection and baling of various forages and crop straws.
Features
- The overall machine features a rational structural design, requiring lower matching tractor power and achieving lower comprehensive operation costs.
- The pickup system boasts six rows of spring teeth, eliminating track discs and protective rings. Post-welding cylinder processing ensures stable performance with minimal vibration and strong impact resistance, while spring teeth can be replaced easily for reduced downtime.
- Spiral forced feeding, paired with chain drive and overload protection, ensures smooth, efficient material flow and prevents clogging during operation.
- The baling chamber incorporates 18 precision-aligned rollers (coaxiality ≤0.10mm), producing dense, neatly formed bales.
- Mechanical net cutting with wear-resistant brake components ensures precise, clean cuts. Net wrapping can be flexibly adjusted between 2 to 5 cycles.
- The intelligent electronic control system features an intuitive touchscreen with bilingual (Chinese/English) operation interfaces, providing effortless operation.
Technical Specification
| Subject | Specification | |
| Overall Size | L*W*H（mm） | 4450*2960*2410 |
| Picker | Structure Type | Spring Tines |
| Pick-up Width（mm） | 2280 | |
| Feeder Type | / | Tine-brush roller |
| Baling Chamber | Baling Mechanism Style | Rolling |
| Width（mm） | 1400 | |
| Diameter（mm） | φ1200 | |
| No.of rolling parts（pc） | 18 | |
| Roller diameter（mm） | φ222 | |
| Baling Style | / | Netting |
| Net Type | / | ≈1.4m×2000m/bale |
| Bale Density | / | Sensor controlled |
| Bale | Size（mm） | φ1300×1400 |
| Density（kg/m³） | [150,200] | |
| Tractor Requirement | Power（PH） | 80 ～150 |
| Linkage | Tow type | |
| Operating Speed（km/h） | 25～35 | |
| PTO（r/min） | 720 | |
| Efficiency | bale/h | 60 ～ 80 |
| kg/h | ≥15000 | |
Company Advantages
LEROX is dedicated to delivering full-scenario implement solutions for modern agriculture. Our extensive product matrix spans multiple operational dimensions, offering an all-inclusive range from agile, compact models to heavy-duty flagship designs. Seamlessly matching mainstream power platforms from 80 to 600 horsepower, LEROX provides tailor-made equipment combinations that ensure high-efficiency, continuous, and synergistic operations worldwide—regardless of soil types or farming environments.
From primary tillage and precision seeding to crop management and harvesting, every core chassis and critical component of LEROX machinery is forged and proven under the most extreme field conditions. Empowered by advanced intelligent control systems and robust overload protection technologies, our equipment delivers stable, uncompromising performance in any harsh environment. More than just a machinery manufacturer, LEROX is a guardian of modern agronomy—reducing full lifecycle operating costs and creating long-term, value-driven smart returns for agricultural producers worldwide.
FAQ
Founded in 1993 with a primary focus on reversible ploughs, we have evolved into a comprehensive manufacturer with over 30 years of expertise. Our flagship products include high-performance hydraulic reversible ploughs, power harrows, and precision seed drills.
Today, the LEROX product ecosystem covers the entire cultivation cycle—including tillage, land preparation, seeding, and crop management. Our extensive portfolio features subsoilers, rotary cultivators, disc harrows, and hay rakes, all engineered to meet the diverse demands of modern global agriculture.
Yes, LEROX implements feature extremely high compatibility. Our designs follow international standards (such as Category 2/3/4 three-point linkage) and can perfectly match tractor models from major global brands. By providing various frame strengths (such as 140/160/180 series) and adjustable traction logic, we ensure that tractors from 80 hp to 600 hp can find the most suitable implement model, achieving optimal power transmission and fuel efficiency.
LEROX provides a comprehensive quality guarantee for all agricultural machinery. We offer a XXX warranty period for core structural components. During this period, if any component fails due to manufacturing defects, we will provide replacement parts free of charge. For wearing parts, we recommend purchasing a spare parts kit along with the machine to ensure operational continuity. Additionally, we provide lifetime remote technical support and detailed maintenance guidance.
Yes, LEROX provides customized solutions across our entire product line to adapt to various crops and soil conditions, offering modular configurations such as specialized plough bodies for sticky soils, adjustable safety systems for stony terrains, and calibrated metering units for different seed types to ensure optimal performance in your specific agronomic environment.
For international orders, LEROX ensures efficient delivery and robust protection: our standard lead time is typically 30 to 45 days depending on the order volume and customization, and all equipment is secured with reinforced steel frames or sea-worthy packaging to prevent damage during maritime transit while maximizing container space efficiency.
Yes, LEROX provides comprehensive technical support including detailed operation manuals and video tutorials for every machine, alongside professional after-sales service through remote video guidance and a rapid-response parts supply system to ensure your equipment maintains peak performance.
LEROX offers flexible payment terms to facilitate international trade, typically accepting T/T (Telegraphic Transfer) with a 30% deposit and the balance before shipment, or an Irrevocable L/C at sight (Letter of Credit) for larger orders to ensure financial security for both parties.
